MF1700-B2

Flatbed Laminator for Building Material

Introduction

MF1700-B2 flatbed laminator for building material is a flatbed mounting and laminating machine with medium size. Available with maximum laminating width reaching 1.62m/64'', it can meet most application needs. Parameters including speed, temperature, and nip gap are fully adjustable, which has increased the capacity and versatility of the flatbed laminating machinery.

4 flatbeds of MF1700-B2 flatbed laminator can be freely lengthened or shortened for making piece-to-piece application easier and faster. It can be used with various substrates, e.g. glass, HDF, MDF, PVC boards, A-Alum plates, acrylic, etc. With the materials guide, it works efficiently even in the case of heavy duty works. The laminating equipment also comes with a fixed speed foot pedal which provides hands-free control and improves handling when mounting graphics.

Specifications

Model MF1700-B2
Type Hot and Cold
Max. Lamination Width 1620mm/64''
Max. Lamination Thickness Up to 30mm/1.2''
Heating Infrared
Heating Type Heated top roller
Max. Temp. 100°C/212°F
Warm Up Time 15-20 min
Max. Speed Up to 7m/min
Roller Silicon
Roller Diameter 130mm/5''
Power 2200W
Voltage 110V/220V
Height Adjustment Air pressure
Pressure Adjustment Air pressure
Silent Air Compressor Optional
Foot Pedal Switch Yes
Flatbed 4 Pcs, 0.8m/pc
Certificate CE, RCM, ROHS
Static-free Yes
