Description
MF1700-F1 semi-auto hot and cold laminator satisfies applications that need lamination width no more than 1620mm/64''. It is an ideal film laminator for sign and graphic makers. It is extremely cost-efficient for common applications.
Designed with stronger frame, large diameter silicon rollers, steadily pressure system etc., the semi-auto hot and cold laminator offers more accurate application than ever. While using, safety with laser eye and emergency device provides dual protection for operators. Simultaneously, the new even lighter self-blocking roll-shafts configured make operators easily, quickly change films. More time will be saved. Our semi-automatic film laminating machinery of MF1700-F1 series is really a good helper for your work.
| Model | |
| Type | Hot and Cold |
| Max. Lamination Width | 1620mm/64'' |
| Max. Lamination Thickness | Up to 23mm/0.9'' |
| Heating | Infrared |
| Heating Type | Heated top roller |
| Max. Temp. | 120°C/248°F |
| Warm Up Time | 10-15 min |
| Max. Speed | Up to 7m/min |
| Roller | Silicon |
| Roller Diameter | 130mm/5'' |
| Power | 2200W |
| Voltage | 110V/220V |
| Height Adjustment | Hand Crank |
| Pressure Adjustment | Hand Crank |
| Foot Pedal Switch | Yes |
| Safety | Laser eye |
| Certificate | CE, RCM, ROHS |
| Static-free | Yes |
